Hydraulic Flange Spreading Kit
Model : SG13TESTD Series : SG Product Lines : Bolting Tools The SG13TE secure grip bolt-hole spreader can be used on all flange types with bolt-hole sizes ranging from 1.49" (38 mm) to 1.92" (49 mm). The collet holders are supplied with adjustable drive cones which can be adjusted outward from their central position allowing the tool to spread flanges apart and remove a spacer, wafer or butterfly valve. This mid-end, hydraulic model offers up to 14.6 imperial tons (130 kN) of spreading force. Spreading force of 29.2 imperial tons (260 kN) if used in pairs as recommended. Set Includes: 1 x SG13TE Tool c/w Hydraulic Cylinder 1 x 10,000 psi (700 bar) HP 550S Sealed Hand Pump with Gauge 1 x 10,000 psi (700 bar) Hydraulic Hose, 78.7" (2 m) 1 x 6" (150 mm) Vernier Calliper 1 x 1/2" Square Drive Flexible Handle 1 x 1 1/8" (30 mm) Socket 1 x Safety Block 2 x M39 (1 1/2") Collets 2 x M42 (1 5/8") Collets 2 x M45 (1 3/4") Collets 1 x Instruction Manual 1 x Carry Case with protective foam inserts Short Collet Holder Sets (SCH) are available which can offer improved range of application. Collet Holders can also be dismantled and inserted through bolt-holes from opposite side.
Model : SG13TESTD Series : SG Product Lines : Bolting Tools The SG13TE secure grip bolt-hole spreader can be used on all flange types with bolt-hole sizes ranging from 1.49" (38 mm) to 1.92" (49 mm). The collet holders are supplied with adjustable drive cones which can be adjusted outward from their central position allowing the tool to spread flanges apart and remove a spacer, wafer or butterfly valve. This mid-end, hydraulic model offers up to 14.6 imperial tons (130 kN) of spreading force. Spreading force of 29.2 imperial tons (260 kN) if used in pairs as recommended. Set Includes: 1 x SG13TE Tool c/w Hydraulic Cylinder 1 x 10,000 psi (700 bar) HP 550S Sealed Hand Pump with Gauge 1 x 10,000 psi (700 bar) Hydraulic Hose, 78.7" (2 m) 1 x 6" (150 mm) Vernier Calliper 1 x 1/2" Square Drive Flexible Handle 1 x 1 1/8" (30 mm) Socket 1 x Safety Block 2 x M39 (1 1/2") Collets 2 x M42 (1 5/8") Collets 2 x M45 (1 3/4") Collets 1 x Instruction Manual 1 x Carry Case with protective foam inserts Short Collet Holder Sets (SCH) are available which can offer improved range of application. Collet Holders can also be dismantled and inserted through bolt-holes from opposite side.
