HP350SMIN Enerpac HP Series Sealed Hand Pump is the smallest single-port model in the HP range. It provides a compact manual power source for single-acting hydraulic equipment while retaining the sealed-reservoir design that allows HP pumps to work at varied angles.
Compact Sealed Pump for One Hydraulic Circuit
The 18.3 in³ usable oil capacity is intended for tools that do not need the larger fluid supply of HP550S or HP1000S. Keeping the reservoir close to the actual system requirement reduces unnecessary pump size and carrying weight.
The pump uses two-stage operation to move oil more quickly at low pressure and then supply controlled flow up to 10,000 psi. A gauge is included, and the single threaded output keeps the setup straightforward for one single-acting circuit.
HP350SMIN is the baseline choice in this sealed-pump family. Move to HP350DMIN for two single-acting outlets or HP350SDMIN when the connected tool is double acting.
Specifications
| Pump Series | HP Series |
|---|---|
| Power Source | Manual |
| Maximum Operating Pressure | 10,000 psi |
| Reservoir Capacity | 18.3 in³ |
| Pump Speed | Two-Speed |
| Pump Operation | Hand Operated |
| Cylinder Compatibility | Single-Acting |
| Gauge Included | Yes |
