The Enerpac RCS302 is a 30-ton-class RCS-Series hydraulic cylinder for applications with limited starting clearance. It combines a 4.63" collapsed height with a 2.44" stroke and spring return.
Key specifications
- Capacity class: 30 tons
- Maximum cylinder force: 32.4 US tons at rated pressure
- Stroke: 2.44"
- Collapsed height: 4.63"
- Oil capacity: 15.82 in³
- Action: single-acting
- Return: spring
- Maximum operating pressure: 10,000 psi (700 bar)
- Included coupler: CR400 female half
- Plunger: grooved end with mounting holes for compatible tilt saddles
Included components
- RCS302 hydraulic cylinder
- CR400 female coupler
- Coupler dust cap
Before ordering
Check the starting clearance, required travel and load before choosing this cylinder. Size the pump reservoir for the cylinder and hose oil volume, and confirm hose and accessory compatibility. Pump and hose are sold separately.
Repair kits and related equipment
- RCS302K repair kit — For existing RCS302 cylinders with date or product codes beginning B. Confirm the equipment identification markings and required seal type before ordering.
Product information is provided for general reference and may not cover every application. Confirm suitability with manufacturer specifications and qualified professional advice. Follow applicable safety requirements; this description is not a substitute for manufacturer instructions or engineering judgment.
Related repair part
RCS302K repair kit for compatible RCS302 cylinders. Confirm the cylinder date code before ordering a service kit. Repair kit sold separately.
Specifications
| Load Capacity | 32.4 Ton |
|---|---|
| Cylinder Type | Low Height Hydraulic Cylinders |
| Cylinder Action | Single Acting |
| Return Type | Spring Return |
| Cylinder Material | Steel |
| Plunger Type | Solid |
| Cylinder Stroke | 2.44 in |
