The Enerpac AM21 is a control manifold for operating two single-acting cylinders from a compatible hydraulic supply.
Key specifications
- Application: two single-acting cylinders
- Port threads: 3/8"-18 NPTF
- Maximum operating pressure: 10,000 psi (700 bar)
Before ordering
Select for a compatible two-cylinder circuit. Do not assume equal cylinder travel under unequal loads; confirm the control requirements of the application.
Specifications
| Product Family | Hydraulic Manifolds |
|---|---|
| Product Type | Split Flow Manifold |
| Maximum Operating Pressure | 10,000 psi |
| Length | 6 in |
| Number of Inlet Ports | 1 |
| Number of Outlet Ports | 2 |
| Number of Regulated Outlet Ports | 2 |
| Oil Ports | 3/8 in NPTF |
