HP1000DMIN Enerpac HP Series Sealed Hand Pump provides the largest reservoir available in the standard twin-port HP configuration. With 67.7 in³ of usable oil and two hydraulic outlets, it is intended for two single-acting circuits whose combined oil demand exceeds the smaller HP350D and HP550D sizes.
Maximum Twin-Port Capacity in the HP Range
The pump uses a sealed reservoir that can operate at different angles without the normal venting limitations of a conventional hand-pump tank. That design helps reduce accidental oil loss and air contamination when the pump is moved around a work area.
Two-speed pumping supplies higher volume during initial movement and automatically transitions to high-pressure operation up to 10,000 psi. A gauge is included for system-pressure visibility.
HP1000DMIN is the pump-and-gauge configuration. When a complete two-port package with hoses and carrying case is preferred, HP1000DSTD packages the same underlying pump concept as a standard field kit.
Specifications
| Pump Series | HP Series |
|---|---|
| Power Source | Manual |
| Maximum Operating Pressure | 10,000 psi |
| Reservoir Capacity | 67.7 in³ |
| Pump Speed | Two-Speed |
| Pump Operation | Hand Operated |
| Cylinder Compatibility | Single-Acting |
| Gauge Included | Yes |
