The Enerpac SWi2025TEMAXSPB kit uses two externally powered hydraulic flange spreading tools for controlled separation of suitable flange joints. Stepped blocks extend the available spreading range.
Key specifications
- Maximum spreading-force class: 27 tons
- Minimum access gap: 0.24"
- Maximum spreading distance: 4.1"
- Pump configuration: external twin-port hand pump
Included components
- 2 × SWi20/25TE hydraulic spreaders
- 2 × 6.5-ft, 10,000 psi hydraulic hoses with 90° elbows
- 1 × HP550D twin-port sealed hand pump with gauge
- 2 × sets of safety blocks
- 2 × pairs of stepped blocks
- 2 × lanyards
- 2 × hex keys
- 1 × molded plastic carry case
Before ordering
Confirm flange geometry, access gap, required force and spreading configuration. Use safety blocks to support the separation and follow the tool positioning and operating requirements.
Product information is provided for general reference and may not cover every application. Confirm suitability with manufacturer specifications and qualified professional advice. Follow applicable safety requirements; this description is not a substitute for manufacturer instructions or engineering judgment.
Specifications
| Product Type | Flange Spreader Set - Wedges |
|---|---|
| Load Capacity | 27 Ton |
| Maximum Spread | 4.1 in |
| Maximum Operating Pressure | 10,000 psi |
| Power Source | External Hydraulic |
| Case Dimensions | 36.2 x 19.7 x 8.1 in |
| Certification Status | Not Atex certified |
| Jaw Width | 2.36 in |
| Model Type | Twin Wedge and Pump Set |
| Spreader Set Type | Max set |
| Tip Clearance | 0.24 in |
| Weight | 72.8 lb |
