For compressed-air workholding, PACG50S8S packages remote/manifold valve architecture with a 462 in³ reservoir and Enerpac's 5000 Series higher-pressure-flow output characteristics.
The pump uses the Turbo II 5000 Series flow profile. Enerpac lists 20 in³/min @ 5,000 psi at rated pressure, so this is the pressure-oriented choice relative to the matching 3000 Series configuration with the same control style.
Building the Valve Package Around the Fixture
PACG50S8S is the large-reservoir PACG remote-valve power unit. The 462 in³ tank gives the system more oil capacity while pressure and tank ports leave directional control to valves mounted elsewhere on the machine or fixture.
PACG5005SB is the nearest smaller-reservoir alternative (230 in³). PACG30S8S keeps the same reservoir/control concept but changes to the 3000 Series flow profile.
Specifications
| Series | Turbo II |
|---|---|
| Pump Series | Turbo II |
| Maximum Operating Pressure | 5,000 psi |
| Power Source | Compressed Air |
| Rated Oil Flow | 20 in³/min @ 5,000 psi |
| Pump Operation | Foot / Hand Operated |
| Reservoir Capacity | 462 in³ |
| Valve Configuration | Pressure / Tank Ports for Remote Valve |
| Valve Operation | Remote Valve |
| Valve Function | Remote Valve Dependent |
| Air Consumption | 12 scfm @ 100 psi air |
| Air Pressure Range | 25–125 psi |
| Gauge Included | Yes |
