SCL201FP Enerpac Low-Height Hydraulic Cylinder & Foot Pump Set gives the 20-ton RCS-201 cylinder a foot-operated hydraulic source. It is intended for users who need the compact geometry of a low-height cylinder but prefer foot actuation instead of working a hand-pump lever.
Low-Height Lifting with a Different Operator Interface
The cylinder provides 1.75 inches of stroke, so this remains a short-travel lifting and positioning package. The foot-pump version does not change the mechanical capability of the RCS-201; it changes how the operator generates hydraulic flow.
That distinction matters when comparing SCL201FP with SCL201H. Both are built around the same 20-ton low-height cylinder class, but one is selected for foot operation and the other for hand pumping. The air-powered SCL201XA is the alternative when a compressed-air source is available.
Choose this version when the RCS-201 cylinder fits the space and foot pumping better matches the operator’s working position.
Specifications
| Power Source | Manual |
|---|---|
| Pump Type | Foot Pump |
| Pump Operation | Foot Operated |
| Cylinder Compatibility | Single-Acting |
| Load Capacity | 20 Ton |
| Cylinder Type | Low Height |
| Cylinder Stroke | 1.75 in |
| Gauge Included | Yes |
| Set Type | Cylinder & Pump Set |
