The Enerpac W4000PX is a W-Series low-profile hydraulic torque wrench drive unit. Combine it with the correct matching hexagon cassette to suit the fastener and working clearance.
Key specifications
- Nominal maximum torque with standard cassette: 4,175 ft-lb
- Minimum nominal torque: 418 ft-lb
- Maximum operating pressure: 10,000 psi
- Tool configuration: drive unit; hexagon cassette sold separately
- Swivel configuration: TSP swivel
Before ordering
Select the cassette for the drive-unit family and the exact fastener size. A compatible torque-wrench pump and twin hoses are required separately. Cassette-specific torque limits and pressure/torque relationships govern the assembled tool.
Product information is provided for general reference and may not cover every application. Confirm suitability with manufacturer specifications and qualified professional advice. Follow applicable safety requirements; this description is not a substitute for manufacturer instructions or engineering judgment.
Specifications
| Product Family | Hydraulic Torque Wrenches |
|---|---|
| Product Type | Low Profile Drive Unit |
| Maximum Torque (ft-lb) | 4,175 |
| Hexagon Range | 1 5/16 - 3 3/8 in |
| Minimum Torque | 417 ft-lb |
| Minimum Torque Rated at | 1000 psi |
| Nominal Speed | 566 RPM |
| Nominal Torque Rated at | 10000 psi |
| Compatible Products | W4203SL, W4206SL, W4209SL, W4212SL, W4215SL, W4105X, W4106X, W4107X, W4108X, W4109X, W4110X, W4111X, W4112X, W4113X, W4114X, W4115X, W4200X, W4201X, W4202X, W4203X, W4204X, W4205X, W4206X, W4207X, W4208X, W4209X, W4210X, W4211X, W4212X, W4213X, W4214X, W4215X, W4300X, W4301X, W4302X, W4303X, W4304X, W4305X, W4306X |
| Weight | 4.44 lb |
