The Enerpac S3000PX is a 1 in square drive hydraulic torque wrench rated at 3,225 ft-lb (4,373 Nm) at 10,000 psi. It is the S3000X X-Edition wrench fitted with the Pro Series tilt-and-swivel manifold. Enerpac shows it in the catalog on wind turbine tower connections and oil and gas flanges.
S3000PX specifications
| Maximum torque at 10,000 psi | 3,225 ft-lb (4,373 Nm) |
|---|---|
| Minimum torque at 1,000 psi | 323 ft-lb (438 Nm) |
| Square drive | 1 in (SD30-100 included) |
| Socket range | 19-95 mm / 7/8-3 7/8 in, BSH-Series 1 in drive |
| Nose radius | 1.30 in |
| Rotation per stroke | 35° |
| Torque accuracy | ±3% across the full stroke |
| Maximum operating pressure | 10,000 psi (700 bar) |
| Swivel | Pro Series tilt-and-swivel manifold fitted |
| Weight (S3000X wrench) | 12.3 lb |
What you need to run it
- Pump: a 10,000 psi torque wrench pump such as the ZU4204TB-Q electric pump. See all torque wrench pumps.
- Hoses: THQ-700 Series twin hoses: THQ702T (6 ft), THQ706T (19.5 ft) or THQ712T (39 ft).
- Sockets: heavy-duty impact sockets with 1 in drive. See BSH-Series sockets.
Accessories made for the S3000X and S3000PX
- ERAK3000 reaction arm kit
- SRA30X short reaction arm for SDA30 Allen drives (5/8 in to 1 1/4 in, 17 mm to 32 mm)
- SRS302X and SRS303X extended reaction arms
- RTE30X reaction tube extension, full torque rated
- AOT30 angle-of-turn indicator
Features
- One-piece high-strength steel body with a small operating radius
- 35° rotation and a fast return stroke
- 360° click-on reaction arm with a glove-friendly quick-release lever
- Push-button square drive release for reversing direction
- Handle mounts on either side of the tool
S3000PX, S3000X or DSX3000?
The S3000X is the same steel wrench with the standard manifold. The DSX3000 has almost the same output (3,233 ft-lb) in an aluminum body that weighs 10.6 lb, with a work-at-height tether point and ATEX certification. Choose the S3000PX for general industrial work and the DSX3000 when weight, working at height or ATEX matter.
Questions about the S3000PX
How much torque does the S3000PX produce?
3,225 ft-lb (4,373 Nm) at 10,000 psi and 323 ft-lb at 1,000 psi. Set the pump pressure from the calibration chart supplied with the wrench.
What size nuts does it fit?
With 1 in drive BSH-Series impact sockets, nuts from 19 mm to 95 mm (7/8 in to 3 7/8 in) across flats. Torque capacity, not socket size, is usually the limit on larger nuts.
Do I need the swivel?
The Pro Series swivel lets the hoses turn 360° and tilt 160°, which helps on flanges and in cramped spaces. If hose routing is never a problem, the S3000X costs less.
How do I estimate loosening torque?
Plan for about 2.5 times the original tightening torque. A bolt tightened to 1,290 ft-lb may need the full 3,225 ft-lb to break loose.
