The Enerpac W2000PX is a low-profile hexagon torque wrench drive unit rated at 2,040 ft-lb (2,766 Nm) at 10,000 psi. It fits W2000X hex cassettes for nuts from 1 1/16 in to 2 3/8 in (30 mm to 60 mm) across flats, and it is the W2000X drive unit fitted with the Pro Series tilt-and-swivel manifold. Low-profile wrenches go where a square drive and socket will not fit, such as tight flange spacing or nuts close to a wall.
W2000PX specifications
| Maximum torque at 10,000 psi | 2,040 ft-lb (2,766 Nm), with in-line reaction foot |
|---|---|
| Minimum torque at 1,000 psi | 204 ft-lb (277 Nm) |
| Hexagon range | 1 1/16-2 3/8 in / 30-60 mm with W2000X cassettes |
| Torque accuracy | ±3% across the full stroke |
| Maximum operating pressure | 10,000 psi (700 bar) |
| Swivel | Pro Series tilt-and-swivel manifold fitted |
| Includes | Drive unit only. Hex cassette sold separately |
What you need to run it
- Hex cassette: one W2000X cassette for each nut size, for example W2106X (1 3/8 in, 35 mm), W2113X (1 13/16 in, 46 mm) or W2203X (2 3/16 in, 55 mm). UltraSlim (SL) cassettes are available for the tightest spaces.
- Pump: a 10,000 psi torque wrench pump such as the ZU4204TB-Q. See torque wrench pumps.
- Hoses: THQ-700 Series twin hoses: THQ702T (6 ft), THQ706T (19.5 ft) or THQ712T (39 ft).
Features
- Cassettes change without tools and with no loose pins
- One drive unit covers every nut size in its range by swapping cassettes
- X-Edition drive units work with most standard-edition cassettes and accessories
- Also accepts UltraSlim and WCR-Series cassettes
- Strips down for maintenance without special tools
W2000PX or W2000X?
The torque and cassettes are the same. The W2000PX has the Pro Series swivel for easier hose routing. The W2000X has the standard manifold. For nuts up to 3 3/8 in or torque to 4,175 ft-lb, use the W4000PX.
Questions about the W2000PX
Does the W2000PX come with a hex cassette?
No. It is the drive unit only. Order a W2000X cassette that matches the nut size across flats.
When should I use a low-profile wrench instead of a square drive wrench?
When there is not enough height or side clearance for a square drive wrench and socket. The cassette wraps around the nut, so the tool sits much closer to the work.
How much torque does it produce?
2,040 ft-lb (2,766 Nm) at 10,000 psi and 204 ft-lb at 1,000 psi. Some cassettes are rated lower, so check the cassette limit as well.
